The machine which can variable frequency speed is RLV-F Series

FOB Reference Price:Get Latest Price
$1,000.00 - $5,000.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Uncoiling Machine
Use:
Sheet
Place of Origin:
Guangdong, China
Brand Name:
RUIHUI
Model Number:
RLV-400F
Voltage:
380V 50Hz or customized
Power(W):
1.5KW
Dimension(L*W*H):
1100*820*1480
Weight:
1-2T
Certification:
CE ISO
Material width:
400mm
material thickness:
0.1~1.5mm
work roll number:
Upper 8/down 9
Power:
380V/50HZ
Name:
straightener feeder
keyword:
straightening machine
color:
customized
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1 Year
Supply Ability
Supply Ability:
25 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
wooden box & Vacuum packing
Port
Shenzhen/Shanghai/Ningbo
Lead Time :
45~75 days for production
Product Description


       The sheet for 0.1-1.5mm straight,upper and lower synchronous drive,variable frequency speed,on the work roll can be opened for cleaning.The sheet straighening has very favorable conditions.

Specification
Model
RLV-150F
RLV-200F
RLV-300F
RLV-400F
RLV-500F
RLV-600F
Max Material Width(mm)
150
200
300
400
500
600
Material Thickness(mm)
0.1~1.5
0.1~1.5
0.1~1.5
0.1~1.5
0.1~1.3
0.1~1.2
Speed(m/min)
6~22
Motor(HP)
1
1
1
2
3
3
Inverter
Provided
Work Rolls
Upper 8/Lower 9    All Drive Function
Pinch Rolls
Upper 1/Lower 1  All Drive Function
Back up rolls
N/A
Provided
Adjustment
4 Points Fine Micro Adjustment
Loop Control
Touch Sensor
Work Roll Opening
Manual Operation
Drive Method
All Rolls are Driven with Side Gear
Power Supply
3Phase 220V/380V/50HZ
Certifications
Detailed Images

17 Smaller Diameter Work Rolls
17 smaller diameter work rolls remove the coil set from the material and ensure the high level of material flatness that precision processing demands.

Back Up Rolls
The RKL-300 and RKL-500,which handle up to 300mm and 500mm widt have additional back up rolls,These rolls will reduce the deflection of work roll making strainghtening performance more precise.

Our Service

Pre-Sales Service

1st,We have a high level of technical research and development team;
2nd,We can provide the design and planning of the whole plant to realize the turnkey project;
3rd, our philosophy: quality is the social responsibility;

After-Sales Service

4th,our products have been recognized by the market, in the major automotive OEM, home appliance industry, hardware industry has been applied;
5th,We have a highly effective after-sales service team and get customer approval.

Packing & Delivery
Company profile

RUIHUI founded in 2000, the technology of automation periphery is from Japan.Now RUIHUI is a Japanese brand and the same technique of sheet metal stamping surrounding automation equipment manufacturer. RUIHUI has been learning Japan and Germany technology, and useing high standards of principle in the parts selection, for assembly process and spare parts, adhere to the requirements in accordance with the original design standard, and into each manufacturing process. In 20 years has accumulated experience and excellent design ability of Japanese engineers guided ruihui highly responsible for Industry and reihui strong executive team, created a batch of well-known auto parts manufacturers, allowing them to reach the high level in same industy,and investment less.

Customer case
Manufacturing industry; the United States Lear Co, Honda factory, Ford factory, GAC Group, Chongqing Changan, Wuhan Shenlong, BMW Brilliance, FAW Volkswagen, Beijing Hyundai.

And other household appliances manufacturers; such as GREE, Haier, Midea, Chigo Air conditioning.

hardware manufacturers; such as the United States Southco, are Zhongtai industrial manufacturers success cooperation case.

RUIHUI has been established over the years, the company steady business, products are constantly upgrading, from the original simple roller feeder to NC servo feeding machine, NC 3 in 1 straightener feeder,multi station manipulator, coil handling systems, to meet the market needs of customers, improve work efficiency, reduce the burden of enterprise management personnel, maintenance of production safety and the customer staff made a significant contribution.

At present the company to further develop the market, at the end of 2013, the total investment reached 30 million yuan, plant area of more than 15 thousand square meters, in order to meet the demand on the market and lay a solid foundation after.

Why choose us?

1st,We have a high level of technical research and development team;
2nd,We can provide the design and planning of the whole plant to realize the turnkey project;
3rd, our philosophy: quality is the social responsibility;
4th,our products have been recognized by the market, in the major automotive OEM, home appliance industry, hardware industry has been applied;
5th,We have a highly effective after-sales service team and get customer approval.
