decoiler straightener feeder MAC machine, Punching machine automatic feeder, Punch automatic feeder

FOB Reference Price:Get Latest Price
$40,000.00 - $100,000.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
RUIHUI
After-sales Service Provided:
Field installation, commissioning and training, Engineers available to service machinery overseas
Warranty:
1 Year
Name:
NC straightener feeder
Function:
Feeding the material into the press after straighting the material
Color:
Custermized
Certification:
CE Certificated
Material Width:
500mm
Material thickness:
0.3-3.2mm
Max.Coil Weight(kg):
3000-5000
Work Roll Number(piece):
uppper6 / lower5
Motor Brand:
YASKAWA/MITSUBISHI/SIEMENS
Supply Ability
Supply Ability:
25 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
wooden box & Vacuum packing
Port
Shenzhen/Shanghai/Ningbo
Video Description



Product Description

1.Description

High Degree of Flatness

Combining the power of the hcavy duty HL unit with the straightening performance of 11work rolls(6 upper and 5 lower),the HL unit gives material a high degree of flatness to the materials from up to 6.0mm thick.

Geared Motor with Inverter Control

Geared Motor with Inverter control allows the feed speed to change easily,in addition,a direct drive machanism without a chain and precision gear has been adopted.These features create maximum smoothness of the work roll movement producing a precise end product.

2.Specification

Specification
ModelMAC2-300MAC2-400MAC2-500MAC2-600
Stock Width(mm)50-30050-40050-50050-600
Stock Thickness(mm)0.3-3.2
Max.Coil Weight(kg)30003000-5000
Max.Coil O.D.(mm)Φ1200
Coil I.D.(mm)Φ508
Feed Length(mm)~400*

Max.Line

Speed(m/min)

16-24

Work Roll

Number(piece)

uppper6 / lower5

Feed Roll

number(pcs)

1
Main MotorAC2.9AC4.4
Mandrel ExpansionHydraulic
Reel Motor(kw)1.52.2
Power(V)3Phase 220V/380V/50HZ
Operating Air(Mpa)0.49

Straightening Performance
Stock Width(mm)

MAC2-300

MAC2-400MAC2-500MAC2-600

Stock

 Thickness

(mm)

0.3300400500600
0.4
0.6
0.8
1
1.2
1.4
1.6470
1.8400
2.0360
2.3 300300300
2.5230230230230
2.8150150150150
3.2110110110110





 Remark:

1.(Penumatic):Option in case of penumatic mandrel expansion is provided,refer to coil weitht().

2.The above flgures are the material having yield strength of 392N/mm2 max.

3.Specification are subject to change for improvement without notice.

Company Information





Packaging & Shipping



FAQ

Q1: What kinds of machines do you have?
 A: Our main products are:Nc Servo Roll Feeder,Uncoiler,Straightener,3 in 1Straightener Feeder,Transfer systems,Press Feeding Line, etc.


Q2: Is your equipment standard or customized?
 A: Both, we can OEM & ODM with customers.


Q3: What are your equipments certification?
 A: All our items are coming with CE certifications.


Q4: How did your company's quality system work?
 A: "QUALITY IS OUR CULTURE"Our quality is not the best in the world, and the  price is not the cheapest.But we can provide you excellent products to defeat your competitors.


Q5: How long is the warranty period of the machine?
 A: We offer free service with a warranty period of one year, If it is operate in reasonable, the machine can be used more than 10 years.


Q6: Is it possible to be a foreign agent and distributor?
 A: If you are confidence and excellent service for after-sales, then welcome to be our agents or distributors all over the world.


Q7: What’s your payment?
 A: T/T,D/P,L/C,Western Union,etc.


Q8: What’s the delivery?
 A: “TIME IS GOLD” for you and for us, so we have professional team work and production line can make nice quality in short time.
